1. General Specifications:

• Model: AD Series

• Pressing Force: 250 – 8500 Tons

• Type: Direct Drive / Split Type

• Application: Hot, Warm, and Cold Forging

• Frame Structure: High-Strength Alloy Steel

• Drive System: Electric with ABB Inverter Drive

2. Mechanical Specifications:

• Ram Stroke: 200 mm – 800 mm (Adjustable)

• Blow Energy: 50 kJ – 500 kJ (Based on Model)

• Screw Diameter: 150 mm – 600 mm

• Platen Size: Customizable as per Requirement

• Pressing Speed: High Precision with Variable Speed Control

3. Electrical & Control System:

• Power Supply: 380V – 440V, 50/60Hz

• Motor Type: High-Torque Servo Electric Motor

• Control System: Siemens PLC with Touchscreen Interface

• Energy Efficiency: Up to 40% Power Savings with Inverter Drive

4. Operational Features:

• Die Change System: Quick Tool Change for High Productivity

• Lubrication System: Automatic Centralized Lubrication

• Noise Level: Below 85 dB for Low Noise Operation

• Cooling System: Advanced Air/Oil Cooling for Continuous Use

• Safety Features: Overload Protection, Emergency Stop, Anti-Vibration Mounts

5. Additional Features:

• Remote Monitoring: IoT Integration for Performance Tracking

• Customization: Available for Specialized Applications

• Applications: Automotive, Aerospace, Bearing, and Industrial Forging

• Service Support: 3-Year Warranty with Global Service Availability

For more details or customization, contact Adhvika Forge Tech Pvt. Ltd.
